Více informací o knize A High Efficiency Power Amplifier Integrated with a CPW Patch Antenna

• Parametry knihy
• Anotace
• Oblíbené z jiného soudku

Nákupem získáte 149 bodů

Anotace knihy

In this work, the CPW-fed aperture-coupled patch antenna is studied for the purpose of integration with a high efficiency power amplifier. The design of a high-efficiency power amplifier using an active multi-harmonic load-pull system is described. The load-pull system is constructed using six-port circuits and can independently vary the output load of a transistor at its fundamental operating frequency, as well as at the second and third harmonics. The system is used to find the efficiency-optimizing output loads of a commercial transistor operating at a class B bias point. A power amplifier with a gain of 7.1 dB and a PAE of 58.6% operating at a fundamental frequency of 3.5 GHz with an input power of 4mW is obtained. A CPW-fed slot-coupled patch antenna is designed to act as both a radiating element and an impedance element, producing the transistor s experimentally determined efficiency-optimizing load at the fundamental frequency. A CPW circuit comprising of internally patterned series stubs is added to the input of the antenna in order to produce the transistor's optimal loads at the second- and third-harmonic frequencies.

Parametry knihy

• Plný název: A High Efficiency Power Amplifier Integrated with a CPW Patch Antenna
• Podnázev: A First Design Iteration
• Autor: Jean-Paul L. Prévost
• Jazyk: Angličtina
• Vazba: Brožovaná
• Počet stran: 124
• EAN: 9783639208450
• ID: 06828798
• Nakladatelství: VDM Verlag Dr. Müller
• Hmotnost: 201 g
• Rozměry: 220 × 150 × 7 mm
• Rok vydání: 2009
